Re-Enable user:pass@ IE Functionality

Here’s a dilemma:

On one side you want to keep your machine up to date with all latest patches, but then there is “Cumulative Security Update for Internet Explorer (832894)”, which disables the user:pass@ way of authentication.

Now, do you update and lose this functionality (which can be handy), or don’t apply it but have the other security it fixes unpatched?

Here’s what I did: I patched!

But I really, really wanted the user:pass back, and it’s even in an RFC MS has linked.

3.1. Common Internet Scheme Syntax

While the syntax for the rest of the URL may vary depending on the particular scheme selected, URL schemes that involve the direct use of an IP-based protocol to a specified host on the Internet use a common syntax for the scheme-specific data:

//<user>:<password>@<host>:<port>/<url-path>

Some or all of the parts <user>:<password>@, :<password>, :<port>, and /<url-path> may be excluded. The scheme specific data start with a double slash “//” to indicate that it complies with the common Internet scheme syntax. The different components obey the following rules:

• user: An optional user name. Some schemes (e.g., ftp) allow the specification of a user name.
• password: An optional password. If present, it follows the user name separated from it by a colon.

The user name (and password), if present, are followed by a commercial at-sign “@”. Within the user and password field, any “:”, “@”, or “/” must be encoded.

The solution? Re-enable it!

Start regedit.

Go to HKEY_LOCAL_MACHINE\Software\Microsoft\Internet Explorer\Main\FeatureControl\FEATURE_HTTP_USERNAME_PASSWORD_DISABLE to re-enable it for the entire machine,

or go to HKEY_CURRENT_USER\Software\Microsoft\Internet Explorer\Main\FeatureControl\FEATURE_HTTP_USERNAME_PASSWORD_DISABLE to re-enable it for the logged-in user.

Now create iexplore.exe and explorer.exe DWORD values and set their value data to 0:

[HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\Internet Explorer\Main\FeatureControl\FEATURE_HTTP_USERNAME_PASSWORD_DISABLE]
"explorer.exe"=dword:00000000
"iexplore.exe"=dword:00000000

Done, you just got the user:pass@ functionality back.

Update: As Kent Sharkey writes, the RFC I quoted actually did not specify the user:pass possibility for the HTTP protocol. I’m sorry for that, it’s a ‘feature’ I guess :)

This registry tweak does not undo the patch, however, it only reactivates this ‘feature’, the chr(0) exploit remains fixed with this tweak.

Update 2: Here is a .reg file to re-enable it system-wide.
